XCAT-AIS
Real-Time Multi-cell / Multi-UE Air-interface Simulator
- XCAT-AIS (Air Interface Simulator)
- XCAT-AIS is air interface simulator which is designed to simulate field environment into a lab. It can be a bridge solution between field and lab by providing an emulation of mobility via controlling multiple cell sites. XCAT-AIS can be perform with XCAL-MTS for load and capacity testing for site test and verification. Its combination provides various real-time test for multi-call and UE in the lab.
Use XCAT-AIS to
- System capacity verification in multi-UE, cell-edge, moving UE environment
- Package verification prior to customer release
- logging and analysis of SINR, RSRP, RSSI, Tx Power, RB/MCS, Throughput, etc.
- Troubleshooting with quick reproduction of problems
- System Parameter optimization of RRC, MAC, PHY
Benefits
- Real-time simulation and logging in the LAB
- No need for drive-test and on-site for cluster preparation
- Efficient use of resources
- Test environment for user-defined test scenarios
- Group operation for multiple tests at the same time
AIS H/W Specification
| FREQUENCY BAND | LTE B#5, B#8, B#3, B#7, B#1, B#38 or B#42 (Supporting up to 6 non-overlapped frequency bands) |
|---|---|
| CARRIER AGGREGATION | Supporting up to 6-CA/2-CC |
| MIMO | Support 2×2 or 4×4 |
| MAX RSRP | -60dBm to -75dBm @ UE Side |
| MAX BS | 3-Sector/6-Cell |
| MAX UE | 400 Real-UE |
| USER | Max 2-User Support(max 200-UE/User) |
Solution
