XCAL-MO III
Field Test Solution up to 30 UEs
- Benchmarking Solution for up to 30 mobile phones in parallel
- XCAL-MOIII is an efficient benchmarking solution interfacing not only with 30 mobile phones simultaneously by parallel connection but also with scanners of various brands, which enables user to test true end-user network experience in the real fields. Also, it is scalable tool by connecting multiple XCAL-MOIIIs. It’s an excellent solution to reduce overall cost with flexibility and portability.

Use XCAL-MOIII to
- Support multiple connections up to 30 mobile phones in parallel with full measurement
- H/W solution based on Slot structure up to 5 slots
- Each slot has an embedded CPUs and Memory optimized for measurement of all Wireless Network
- Support an automated call test and make a benchmarking with multiple devices
- Benchmarking test among multiple & different service operators, different mobile phones, or networks
Features
- Support up to 30 devices
-
Interface with various devices
- Mobile Phone, USB Modem
- GPS (1 unit)
- Scanner (2 unit)
- Support standard based MOS test
-
Using same User GUI of XCAL series
- Display Voice/Data quality test result and RF information in real-time
- Independent OS for 5 of each Slot (6 Ports per Slot)
- No additional equipment required for MOS Testing
- Optimized for Field Test
- Optimized for Operator/Vendor/Network Benchmarking Test
- Map Plot in Mobility – Real-time map view with signal level plotting
- Scalable in Cascade form(2X) (Up to 60 mobile phones)
XCAL PC Based Solution Capacity
CONTENTS | XCAL | MPM4 | PU12 | MO III | MTS |
---|---|---|---|---|---|
AUTOCALL SUPPORT | ☑ |
☑ |
☑ |
☑ |
☑ |
NO. OF DEVICE INTERFACING | 4 | 4 | 12 | 30 | 40 per Rack (with 20UE Shield box) |
FIELD TEST | ☑ |
☑ |
☑ |
||
IN-BUILDING TEST | ☑ |
||||
MOS TEST | △ Support with MC-CM132 cable set |
☑ |
☑ |
☑ |
☑ |
BENCHMARKING TEST | ☑ |
☑ |
☑ |
☑ |
H/W Specification
TITLE | SPECIFICATION | NOTE |
---|---|---|
POWER INPUT | DC 48V | |
POWER CONSUMPTION |
Typically, 290W Max. 450W |
|
CPU | Intel Core i7-7600U (Kabylake) TDP : 47 W |
PIU(Slot) |
MEMORY | 16GByte DDR4 | |
SSD | 512GByte | |
OS |
Windows 10 | |
OS Recovery |
Supported | |
Phone Interface | USB 6 Ports USB 3.1 (Gen2) 3A, 5V (Max.) |
|
SIZE | 249 x 193 x 327 (mm) | |
WEIGHT | < 7Kg |
