XCAL-PU12
Benchmarking (Chipset, Mobile, System, Operators, etc.)
- Versatile 3 in 1 Benchmarking Platform up to 12UEs
- XCAL-PU12 is similar to XCAL-PU9 however it supports 12 UEs and latest 5G technologies. XCAL-Pu12 packages drive test, unattended benchmarking and an in-building test solution into a compact, lightweight and powerful tool. The Pu12 can support up to 12 mobile phones that can be provisioned to benchmark a range of competitors over all key mobile access technologies like 5G, 2G, 3G, LTE, LTE-A (CA ~ 6CA), PS-LTE (MCPTT), eMTC (Cat.M1) and NB-IoT. Thanks to its light weight chassis, it is suitable for walk test.
Use XCAL-Pu12 to
- Perform both manual and autonomous competitive network benchmarking and troubleshooting
- Conduct a wide range of application testing and application performance analysis
-
Monitor and improve
- Web browsing
- HTML : Mobile Messaging
- SMS : Downloads and Uploads
- FTP/iPerf : Streaming Video and audio
- YouTube : mVolP and VoLTE
Benefits
- The Pu12 guarantees the best possible mobile experience on the network to ensure customer satisfaction
-
Coupled with XCAP-Vuze, AEGIS, the Pu12 can also be used in end to end network performance assessment and network auditing
- Streamlined network application testing
- Reduced costs – ‘all in one’ platform means that the Pu12 can be used to perform a variety of tests on one scalable platform
- SMS : Downloads and Uploads
- Increase test accuracy and detail
- Monitoring the most important live services
- Improved time to market for new services
- Perform standard-based Voice MOS Tests
Features
- XCAL-Smart function supportable (recommended)
-
Interfacing with various devices
- Mobile Phone, USB Modem (Smart phone: up to 12 / USB modem: 2)
- GPS (1 unit)
- Scanner (2 unit)
- Backpack carriable, High mobility for walking test
- External battery pack applicable
- Support standard based MOS test
-
Support various QoS algorithm
- PESQ: P862, P862-1, P862-2
- POLQA: P863 Narrow Band & Wide Band
- Support various QoS algorithm
XCAL PC Based Solution Capacity
| CONTENTS | XCAL | MPM4 | PU12 | MO III | MTS |
|---|---|---|---|---|---|
| AUTOCALL SUPPORT | O | O | O | O | O |
| NO. OF DEVICE INTERFACING | 4 | 4 | 12 | 30 | 60 ~ 120 (/ 1 Rack) |
| FIELD TEST | X | O | O | O | X |
| IN-BUILDING TEST | X | X | O | X | X |
| MOS TEST | △Support with XCAL-S+ | O | O | O | O |
| BENCHMARKING TEST | X | O | O | O | O |
![](\"/uploaded/webedit/2102/0957a8238f4fae1d2875146ef628c618_1612426656_26.png\" "\\"0957a8238f4fae1d2875146ef628c618_1612426656_26.png\\"")
Specification
| TITLE | SPECIFICATION | NOTE |
|---|---|---|
| POWER INPUT | DC 24V | |
| POWER CONSUMPTION | Stand-by < 10W (MCU Stand-by) Stand-by < 60W (CPU Stand-by) Maximum < 240W | |
| CPU | Intel Core i7-7Gen 2.8GHz x2 | |
| SSD/MEMORY | 512GByte x2 / 16GByte x2 | |
| EXTERNAL INTERFACE |
USB3.1 Gen2 x 4 ports 1Gbps LAN x 2 ports Master Phone Interface x 12 |
|
| PHONE INTERFACE | Connector: USB 3.1 Gen2 | Maximum: 12 ports |
| SIZE | 170 x 87 x 170 (mm, W x H x D) | |
| WEIGHT | 2.12kg |
